Micromod Micro-DCI: 53MC5000 Multi-Loop Process Controller Instruction Manual - Manual (Page 117)

Table 4-2. Generated Display Lists
Display
Number
Title Applicable Control Strategies
Single Loop Flexible Control Strategies
Single List
3 Single Loop CON0* CS1 Single Loop PID Controller,
CS2 Analog Backup Controller,
CS3 Ratio Controller,
CS4 Automatic/Manual Station, and
CS5 Ratio Automatic/Manual Station.
(Pressing the F1 push button pages
forward down the list and pressing the F2
push button pages backward up the list to
select the next display.)
9 Single Loop CON0 with Horizontal Trend
13 Parameter Module 0
14 Parameter Module 1
2 System Status
Two Loop Flexible Control Strategies
Group 1
3 Single Loop CON0 CS20 Two Loop Controller,
CS21 Two Loop Cascade Controller, and
CS22 Two Loop Override Controller.
(Pressing the F1 push button selects the
group and pressing the F2 push button
selects the next display in the group.)
9 Single Loop CON0 with Horizontal Trend
13 Parameter Module 0
14 Parameter Module 1
2 System Status
Group 2
4 Single Loop CON1
10 Single Loop CON1 with Horizontal Trend
18 Parameter Module 5
19 Parameter Module 6
7 Two Loop CON0 and CON1*
Four Loop Flexible Control Strategies
Group 1
32 Four Loop CON0 - CON3* CS40 Dual Two Loop Cascade Controller
and CS41 Four Loop Controller.
(Pressing the F1 push button selects the
group and pressing the F2 push button
selects the next display in the group.)
9 Single Loop CON0 with Horizontal Trend
10 Single Loop CON1 with Horizontal Trend
11 Single Loop CON2 with Horizontal Trend
12 Single Loop CON3 with Horizontal Trend
Group 2
1 Alarm Summary
2 System Status
21 Status Module 0
22 Status Module 1
32 Four Loop CON0 - CON3
*These displays are also presented in their applicable Control Strategy Sections 6-15.
53MC5000 Process Control Station
4-4
