Table 5-10. Status Modules (SDT0 and SDT1)
Title Definition Atom SDT0 SDT1 Default
Point 0 Mode Mode (SM) indicates how the Point Name is displayed,
which is also affected by three other parameters: SDT
Alarm Enable (SA), SDT State (SS), and SDT Alarm
Acknowledge (SK). Dependent upon the contents of all
four of these parameters,
0 - SNGL
1 - DUAL
the Point Name can be displayed as 10 characters (1-
10), the first 5 characters (1-5), or the second 5
characters (6-10). Display modes include normal video,
reverse video, or blinking reverse video. A flashing horn
overlay can also be displayed at the top of the discrete
status presentation. The number of Point Name
characters displayed for a particular display mode, given
the contents of the four parameters, are as follows:
SMA L352 L360 0
Point 1 Mode SMB L353 L361 0
Point 2 Mode SMC L354 L362 0
Point 3 Mode SMD L355 L363 0
Point 4 Mode SME L356 L364 0
Point 5 Mode SMF L357 L365 0
Point 6 Mode SMG L358 L366 0
Point 7 Mode SMH L359 L367 0
Flashing
Normal Reverse Blinking Horn
MASK Video Video Video Overlay
000X 1-10 - - No
001X - 1-10 - No
010X 1-10 - - No
0110 - - 1-10 Yes
100X 1-5 - - No
101X 6-10 - - No
110X 1-5 - - No
1110 - - 6-10 Yes
