Table 4-1. Standard Displays
Display
Number
Title Point
Display*
Group
Display
1 Alarm Summary ●
2 System Status ●
3 Single Loop CON0 ●
4 Single Loop CON1 ●
5 Single Loop CON2 ●
6 Single Loop CON3 ●
7 Two Loop CON0 and CON1 ●
8 Two Loop CON2 and CON3 ●
9 Single Loop CON0 with Horizontal Trend ●
10 Single Loop CON1 with Horizontal Trend ●
11 Single Loop CON2 with Horizontal Trend ●
12 Single Loop CON3 with Horizontal Trend ●
13 Parameter Module 0 ●
14 Parameter Module 1 ●
15 Parameter Module 2 ●
16 Parameter Module 3 ●
17 Parameter Module 4 ●
18 Parameter Module 5 ●
19 Parameter Module 6 ●
20 Parameter Module 7 ●
21 Status Module 0 ●
22 Status Module 1 ●
23 Totalizer Module 0 ●
24 Totalizer Module 1 ●
25 Totalizer Module 2 ●
26 Totalizer Module 3 ●
27 Totalizer Module 4 ●
28 Totalizer Module 5 ●
29 Totalizer Module 6 ●
30 Totalizer Module 7 ●
31 Locator Grid
32 Four Loop CON0 - CON3 ●
*Point Displays can be any of six types (0-5): 0 - Standard PID, 1 - Indicator, 2 - Manual Loader,
3 - Ratio Controller, 4 - Auto/Manual (A/M) Station, and 5 - Ratio A/M Station.
Section 4. Operator Displays
4-3
