Table 1-5. OPTO 22 Module Specifications for 16DI/DO ITB

Safety classification: FM Approved: Nonincendive for Class 1, Div. 2, Group A, B, C, & D
hazardous locations as part of the 16DI/DO ITB.

WARNING

It is the user’s responsibility to install all associated switches and load

apparatus in accordance with ANSI/NFPA 70, National Electrical Code.
Rules and requirements for the installation and wiring of equipment in

Class 1, Division 2 Hazardous (Classified) Locations are found in

Article 501 of the Code.

CSA Certified.

Meets IEEE surge withstand specification.

UL recognized.

4000 V ac optical isolation.

Will withstand one cycle surge of 80 Amperes.

Built-in LED Status Indicator.

Output modules have replaceable fuses.

OPTO 22 AC Input Modules

OPTO 22

Part Number

16DI/DO

Voltage

Input Voltage Range

Input

Current @

Max V In

Input

Maximum

for No Output

G41DC5

5 V dc

12 - 32 V ac

25 mA

3 V ac

G41DC5G

5 V dc

35 - 60 V ac

25 mA

9 V ac

G41AC5

5 V dc

90 - 140 V ac

11 mA

45 V ac

G41AC5A

5 V dc

180 - 280 V ac

6.5 mA

80 V ac

G41DC24

24 V dc

12 - 32 V ac

25 mA

3 V ac

G41AC24

24 V dc

90 - 140 V ac

11 mA

45 V ac

OPTO 22 AC Output Modules

OPTO 22

Part Number

16DI/DO

Voltage

Output Line

Voltage

Range

Load

Current

@ 45

°

C

Load

Current

@ 70

°

C

Maximum

Off State

Leakage

G40AC5

5 V dc

12 - 140 V ac

3 Amps

2 Amps

5 mA ac

G40AC5A

5 V dc

24 - 280 V ac

3 Amps

2 Amps

2.5 mA ac

G40AC5A5(NC)

5 V dc

24 - 280 V ac

3 Amps

2 Amps

2.5 mA ac

G40AC24

24 V dc

12 - 140 V ac

3 Amps

2 Amps

5 mA ac

G40AC24A

24 V dc

24 - 280 V ac

3 Amps

2 Amps

2.5 mA ac

OPTO 22 DC Input Modules

OPTO 22

Part Number

16DI/DO

Voltage

Input Voltage Range

Input

Current @

Max V In

Input

Maximum

for No Output

G41C5

5 V dc

10 - 32 V dc

25 mA

3 V dc

G41DC5B

5 V dc

4 - 16 V dc

45 mA

1 V dc

G41DC5D

5 V dc

2.5 - 28 V dc

30 mA

1 V dc

1 of 2
