15.2 CS41 CONTROL SIGNALS
Loading CS41 connects the 53MC5000 Controller function blocks for operation as four standard
PID controllers. As shown in Figure 15-1, CS41 provides 24 control signals which are described in
Table 15-1 as follows:
Table 15-1. CS41 Control Signals
Control
Signal Definition
Cord
Set
ITB
Rear
Term
Board
Signal
AI0 - Process
Variable Loop 1 This analog input signal represents the value
of the Loop 1 process to be manipulated by
the controller. It is compared to the Loop 1
control setpoint to determine the Control
Output Loop 1 value. TB1-1 (+)
TB1-2 (-)
TB1-3 1 (+)
2 (-)
3 +24 V
AI0
SC
AI1 - Process
Variable Loop 2 This analog input signal represents the value
of the Loop 2 process to be manipulated by
the controller. It is compared to the Loop 2
control setpoint to determine the Control
Output Loop 2 value. TB1-5 (+)
TB1-6 (-)
TB1-7 4 (+)
5(-)
6 +24 V
AI1
SC
AI2 - Remote
Setpoint Loop 1 This analog input signal represents the value
to be used as the Loop 1 control setpoint
when remote setpoint operation is selected
with the R/L push button and enabled by CCI0. TB1-9
TB1-10 (+)
TB1-11 (-) 1
7 (+)
8 (-) +24 V
AI2
SC
AI3 - Remote
Setpoint Loop 2 This analog input signal represents the value
to be used as the Loop 2 control setpoint
when remote setpoint operation is selected
with the R/L push button and enabled by CCI1. TB1-13
TB1-14 (+)
TB1-15 (-) 4
9 (+)
8 (-) +24 V
AI3
SC
AI4 - Process
Variable Loop 3 This analog input signal represents the value
of the Loop 3 process to be manipulated by
the controller. It is compared to the Loop 3
control setpoint to determine the Control
Output Loop 3 value. Analog
ITB
TB1
TB1-1
TB1-2 (+)
TB1-3 (-) +24 V
AI4
SC
AI5 - Process
Variable Loop 4 This analog input signal represents the value
of the Loop 4 process to be manipulated by
the controller. It is compared to the Loop 4
control setpoint to determine the Control
Output Loop 4 value. Analog
ITB
TB1
TB1-5
TB1-6 (+)
TB1-7 (-) +24 V
AI5
SC
AI6 - Remote
Setpoint Loop 3 This analog input signal represents the value
to be used as the Loop 3 control setpoint
when remote setpoint operation is selected
with the R/L push button and enabled by CCI2. Analog
ITB
TB1
TB1-9
TB1-10 (+)
TB1-11 (-) +24 V
AI6
SC
AI7 - Remote
Setpoint Loop 4 This analog input signal represents the value
to be used as the Loop 4 control setpoint
when remote setpoint operation is selected
with the R/L push button and enabled by CCI3. Analog
ITB
TB1
TB1-13
TB1-14 (+)
TB1-15 (-) +24 V
AI7
SC
AO0 - Control
Output Loop 1 This is the 4-20 mA output signal to drive the
Loop 1 final control element. TB1-17 (+)
TB1-18 (-) 10 (+)
11 (-) AO0
PC
1 of 3
