Table 5-4. Analog Input Modules (AI0-8)
Title Definition Atom AI0 AI1 AI2 AI3 AI4 AI5 AI6 AI7 AI8 Default
Scan Pulse
Count When the input is configured for a
frequency input, this number
represents the number of pulses
received since the last time the
F-TRAN program was started. AIPI
(5-7)
C066 C065 C064 0
Pulse
Total This value is the summation of the
SCAN PULSE COUNTS (e.g. for
AI5, the value in C66 is added to
H66). The count value resets to 0.0
when it reaches 10,000,000. AIPC
(5-7)
H066 H065 H064 0
Tag Name It is an assignable 10 character
name for the analog input. TAG A224 A225 A226 A227 A228 A229 A230 A231 A232
Engineering
Units It is assignable as units of measure
the AI represents (e.g., GPM for
gallons/minute). EU A298 A299 A300 A301 A302 A303 A304 A305 A306
