Micromod Micro-DCI: 53MC5000 Multi-Loop Process Controller Instruction Manual User Manual
Page 111
7.
Select OK to continue.
8.
The next window is used to configure the PC COM port communications parameters. The
front port of the 53MC5000 has fixed communication parameters of 9600 baud, 8 Data Bits,
1 Stop Bit, and no Parity.
9.
When the proper settings have been made, select OK to accept the settings.
10. Select File Properties from the HyperTerminal tool bar.
53MC5000 Process Control Station
3-28
