Table 15-3. CS41 Four Loop Controller Datapoints
Data-
point
Table
Module
Title and Function
De-
fault
CCO2 - Process Alarm Loop 3
L290
5-7
CCO2
Contact Output Invert - Normally, Process Alarm Loop 3 is
enabled if CCO2 is closed. Set to 1 to reverse the CCO2
condition required to activate Process Alarm Loop 3 (CCO2
open = the Loop 3 PV value is not within the C175, C176
Alarm Limits).
0
CCO3 - Process Alarm Loop 4
L291
5-7
CCO3
Contact Output Invert - Normally, Process Alarm Loop 4 is
enabled if CCO3 is closed. Set to 1 to reverse the CCO3
condition required to activate Process Alarm Loop 4 (CCO3
open = the Loop 4 PV value is not within the C212, C213
Alarm Limits).
0
Alarms Related Datapoints (Loops 1, 2, 3, 4)
B335,
B340,
B345,
B350
5-9
CON0,
CON1,
CON2,
CON3
Control Alarm Mode - Used to select one of six alarm types
or none. See Table 5-9 for details and examples.
1
C103,
C139,
C175,
C211
5-9
CON0,
CON1,
CON2,
CON3
Alarm Limit 1 - Point in engineering units where an alarm is
triggered because the loop PV is not within the limit value set
in the datapoint.
100
C104,
C140,
C176,
C212
5-9
CON0,
CON1,
CON2,
CON3
Alarm Limit 2 - Point in engineering units where an alarm is
triggered because the loop PV is not within the limit value set
in the datapoint.
0
C105,
C141,
C177,
C213
5-9
CON0,
CON1,
CON2,
CON3
Alarm Dead Band - Sets the activation/deactivation gaps for
the alarm limit points. It is in engineering units.
2
Setpoint Related Datapoints (Loops 1, 2, 3, 4)
C114,
C150,
C186,
C222
5-9
CON0,
CON1,
CON2,
CON3
Control Zone - A gap on both sides of setpoint. When PV is
within this gap, the proportional and integral output changes
are suppressed. Derivative output is unaffected.
0
C125,
C161,
C197,
C233
5-9
CON0,
CON1,
CON2,
CON3
Setpoint High Limit - It is the maximum loop control setpoint
value allowed.
100
C126,
C162,
C198,
C234
5-9
CON0,
CON1,
CON2,
CON3
Setpoint Low Limit - It is the minimum loop control setpoint
value allowed.
0
