1.4 SPECIFICATIONS

Table 1-1. 53MC5000 Process Control Station Specifications

Item

Specification(s)

Power requirements (as specified)

21 to 28 V dc
90-132 V rms
180-264 V rms
50/60 Hz

Power consumption ac/dc operation

20 VA maximum.

Internal power supply:
Available power output for
transmitters
Output Ripple

25 V dc

±

1 V dc @ 80 mA maximum, short circuit protected.

200 mV p-p maximum.

Analog inputs (all analog inputs are
referenced to signal common [SC]):
Quantity

Signal Range

Input impedance

Measurement accuracy

4

0 to 5.46 V dc (1-5 V dc typically) or any current signal (4-
20 mA dc typically) converted to an appropriate voltage
signal by an external ranging resistor.
Note: The standard rear terminal board has the appropriate
resistors at 0.1% tolerance for AI0 and AI1. Cord set ITBs
have appropriate resistors for AI0 - AI3.

1 megohm minimum for voltage inputs; value of ranging
resistor for current signals.

±

0.1% of span.

Contact closure inputs (contact in-
puts are referenced to power com-
mon [PC]):
Quantity

Type

Permitted contact resistance

Open/Close contact duration

Closed contact recognition level

Open contact recognition level

2

Discrete inputs

100 ohms maximum

For open recognition: 0.05 seconds minimum.
For close recognition: 0.05 seconds minimum.

1 V dc maximum.

4 V dc to 24 V dc.

Analog outputs:
Quantity

Signal range

Load range

2

0 to 21.84 mA dc (4 to 20 mA dc typically).

0 to 750 ohms.

1 of 4

53MC5000 Process Control Station

1-10
