Table D-16. Database - C Type Datapoints
Data-
point
Name Module Atom Default Table
C100 Process Variable
Controller 0
PV0 0
5-9
C101 Setpoint SP0 0
C102 Output OUT0 0
C103 Alarm Limit 1 PL10 100
C104 Alarm Limit 2 PL20 0
C105 Alarm Dead Band ADB0 2
C106 Proportional Band PB0 100
C107 Reset Time TR0 0
C108 Rate Time TD0 0
C109 Output High Limit OH0 100
C110 Output Low Limit OL0 0
C111 Manual Reset MR0 50
C112 Remote SP Bias B10 0
C113 Remote SP Ratio K10 1
C114 Control Zone CZ0 0
C115 Controller Span IR0 100
C116 Controller Lower Range ILR0 0
C117 Setpoint Slew Rate T10 0
C118 Output Slew Rate T30 0
C119 Control Setpoint TSP0 0
C120 Remote Setpoint RSP0 0
C121 Deviation DV0 0
C122 Feed Forward FF0 0
C123 Control Output CO0 0
C124 Partial Output Term PN0 0
C125 Setpoint High Limit SH0 100
C126 Setpoint Low Limit SL0 0
C127 Reset Feedback RF0 0
C128 Setpoint Track Value STV0 0
C129 Output Track Value OTV0 0
C130-
C135
Reserved
C136 Process Variable
Controller 1
PV1 0
5-9
C137 Setpoint SP1 0
C138 Output OUT1 0
C139 Alarm Limit 1 PL11 100
C140 Alarm Limit 2 PL21 0
C141 Alarm Dead Band ADB1 2
C142 Proportional Band PB1 100
C143 Reset Time TR1 0
C144 Rate Time TD1 0
C145 Output High Limit OH1 100
2 of 7
53MC5000 Process Control Station
D-24
