I / O C O N T R O L M O D U L E
GPIO Control registers
www.digiembedded.com 71
GPIO Control
Register #1
Address: A090_2070
D25 R/W GPIO25 0 GPIO[25] control bit
D26 R/W GPIO26 0 GPIO[26] control bit
D27 R/W GPIO27 0 GPIO[27] control bit
D28 R/W GPIO28 0 GPIO[28] control bit
D29 R/W GPIO29 0 GPIO[29] control bit
D30 R/W GPIO30 0 GPIO[30] control bit
D31 R/W GPIO31 0 GPIO[31] control bit
Bit(s) Access Mnemonic Reset Description
Bit(s) Access Mnemonic Reset Description
D00 R/W GPIO32 0 GPIO[32] control bit
D01 R/W GPIO33 0 GPIO[33] control bit
D02 R/W GPIO34 0 GPIO[34] control bit
D03 R/W GPIO35 0 GPIO[35] control bit
D04 R/W GPIO36 0 GPIO[36] control bit
D05 R/W GPIO37 0 GPIO[37] control bit
D06 R/W GPIO38 0 GPIO[38] control bit
D07 R/W GPIO39 0 GPIO[39] control bit
D08 R/W GPIO40 0 GPIO[40] control bit
D09 R/W GPIO41 0 GPIO[41] control bit
D10 R/W GPIO42 0 GPIO[42] control bit
D11 R/W GPIO43 0 GPIO[43] control bit
D12 R/W GPIO44 0 GPIO[44] control bit
D13 R/W GPIO45 0 GPIO[45] control bit
D14 R/W GPIO46 0 GPIO[46] control bit
D15 R/W GPIO47 0 GPIO[47] control bit
D16 R/W GPIO48 0 GPIO[48] control bit
D17 R/W GPIO49 0 GPIO[49] control bit
D18 R/W GPIO50 0 GPIO[50] control bit
D19 R/W GPIO51 0 GPIO[51] control bit
D20 R/W GPIO52 0 GPIO[52] control bit
D21 R/W GPIO53 0 GPIO[53] control bit
