R E A L T I M E C L O C K M O D U L E
Interrupt Enable Status register
470 Hardware Reference NS9215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I n t e r r u p t E n a b l e S t a t u s r e g i s t e r
Address: 9006 0028
The Interrupt Enable Status register determines which interrupt sources are enabled
and which interrupt sources are disabled.
Register
Register bit
assignment
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
Reserved
Reserved
Mnth
Stat
Date
Stat
Hour
Stat
Min
Stat
Sec
Stat
Hsec
Stat
Alrm
Stat
Bits Access Mnemonic Reset Description
D31:07 N/A Reserved N/A N/A
D06 R Alrm Stat 1 Alarm interrupt status
0 Interrupt enabled
1 Interrupt disabled
D05 R Mnth Stat 1 Month interrupt status
0 Interrupt enabled
1 Interrupt disabled
D04 R Date Stat 1 Date interrupt status
0 Interrupt enabled
1 Interrupt disabled
D03 R Hour Stat 1 Hour interrupt status
0 Interrupt enabled
1 Interrupt disabled
D02 R Min Stat 1 Minute interrupt status
0 Interrupt enabled
1 Interrupt disabled
D01 R Sec Stat 1 Second interrupt status
0 Interrupt enabled
1 Interrupt disabled
D00 R Hsec Stat 1 Hundredth of a second interrupt status
0 Interrupt enabled
1 Interrupt disabled
