W O R K I N G W I T H T H E C P U
MemoryManagement Unit (MMU)
www.digiembedded.com 109
Table walk
process
First-level fetch
Bits [31:14] of the TTB register are concatenated with bits [31:20] of the MVA to
produce a 30-bit address.
Indexed by
modified
virtual
address
bits [31:20]
TTB base
Translation
table Section base
Indexed by
modified
virtual
address
bits [19:0]
4096 entries 1 MB
Section
Large page
Indexed by
modified
virtual
address
bits [15:0]
Large page
base
Coarse page
table
Coarse page
table base
Fine page
table base
Fine page
table
Indexed by
modified
virtual
address
bits [19:10]
256 entries
Indexed by
modified
virtual
address
bits [19:12]
1024 entries
Indexed by
modified
virtual
address
bits [11:0]
Indexed by
modified
virtual
address
bits [9:0]
64 KB
4 KB
1 KB
Tiny page
Small page
