I / O C O N T R O L M O D U L E
GPIO Configuration registers
www.digiembedded.com 57
GPIO
Configuration
Register #2
Address: A090_2008
GPIO
Configuration
Register #3
Address: A090_200C
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO11 GPIO10
GPIO9 GPIO8
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO11 0x18 GPIO[11] configuration
D23:16 R/W GPIO10 0x18 GPIO[10] configuration
D15:08 R/W GPIO9 0x18 GPIO[9] configuration
D07:00 R/W GPIO8 0x18 GPIO[8] configuration
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO15 GPIO14
GPIO13 GPIO12
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO15 0x18 GPIO[15] configuration
D23:16 R/W GPIO14 0x18 GPIO[14 configuration
D15:08 R/W GPIO13 0x18 GPIO[13] configuration
D07:00 R/W GPIO12 0x10 GPIO[12] configuration
