I / O C O N T R O L M O D U L E
GPIO Configuration registers
68 Hardware Reference NS9215
GPIO
Configuration
Register #24
Address: A090_2060
GPIO
Configuration
Register #25
Address: A090_2064
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO99 GPIO98
GPIO97 GPIO96
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO99 0x18 GPIO[99] configuration
D23:16 R/W GPIO98 0x18 GPIO[98] configuration
D15:08 R/W GPIO97 0x18 GPIO[97] configuration
D07:00 R/W GPIO96 0x18 GPIO[96] configuration
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO103 GPIO102
GPIO101 GPIO100
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO103 0x18 GPIO[103] configuration
D23:16 R/W GPIO102 0x18 GPIO[102] configuration
D15:08 R/W GPIO101 0x18 GPIO[101] configuration
D07:00 R/W GPIO100 0x18 GPIO[100] configuration
