I / O C O N T R O L M O D U L E
GPIO Configuration registers
www.digiembedded.com 63
GPIO
Configuration
Register #14
Address: A090_2038
GPIO
Configuration
Register #15
Address: A090_203C
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO59 GPIO58
GPIO57 GPIO56
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO59 0x18 GPIO[59] configuration
D23:16 R/W GPIO58 0x18 GPIO[58] configuration
D15:08 R/W GPIO57 0x18 GPIO[57] configuration
D07:00 R/W GPIO56 0x18 GPIO[56] configuration
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO63 GPIO62
GPIO61 GPIO60
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO63 0x18 GPIO[63] configuration
D23:16 R/W GPIO62 0x18 GPIO[62] configuration
D15:08 R/W GPIO61 0x18 GPIO[61] configuration
D07:00 R/W GPIO60 0x18 GPIO[60] configuration
