S Y S T E M C O N T R O L M O D U L E
Timer 6–9 Low registers
www.digiembedded.com
171
Register
Register bit
assignment
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
T i m e r 6 – 9 L o w r e g i s t e r s
Addresses: A090 0088 / 008C / 0090 / 0094
The Timer 6–9 Low registers contain the low registers for the enhanced PWM
features available in timers 6 through 9.
Register
Register bit
assignment
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
High
High
Bits
Access
Mnemonic
Reset
Description
D31:00
R/W
High
0x0
The PWM output toggles high when the timer
counter reaches this value.
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
Low
Low
Bits
Access
Mnemonic
Reset
Description
D31:00
R/W
Low
0x0
The PWM output toggles low when the timer
counter reaches this value.
