S E R I A L C O N T R O L M O D U L E : S P I
SPI timing characteristics
www.digiembedded.com
443
Register
Register bit
assignment
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
S P I t i m i n g c h a r a c t e r i s t i c s
These are the guaranteed timing parameters for all four SPI clocking modes.
SPI master timing
parameters
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
Not used
Not used
TX_ IDLE RX_IDLE
Bits
Access
Mnemonic
Reset
Description
D31:02
R/W
Not used
0
Write this field to 0.
D01
R/W1TC
TX_IDLE
0
Transmit idle
Indicates that the transmitter has moved from the active
state to the idle state. The transmitter moves from the active
state to the idle state when the transmit FIFO is empty and
the transmitter is not actively shifting out data.
D00
R/W1TC
RX_IDLE
0
Receive idle
Indicates that the receiver has moved from the active state
to the idle state. The receiver moves from the active state to
the idle state when a start bit has not been received within 4
bit periods of the previous stop bit.
Parm
Description
Min
Max
Unit
Notes
S1
CS# falling to CLK rising
1
clock
1
S2
CLK period low time
12
13
ns
2
S3
CLK period high time
12
13
ns
2
S4
Data output setup to CLK rising
11
ns
3
S5
Data output hold from CLK rising
11
ns
3
S6
Data input setup to CLK rising
10
ns
4
S7
Data input hold from CLK rising
0
ns
4
S8
CLK falling to CS# rising
1
clock
1
S9
CS# deassertion time
4
clock
1
