I / O H U B M O D U L E
[Module] RX Interrupt Configuration register
www.digiembedded.com
377
Register
Register bit
assignment
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
[ M o d u l e ] R X I n t e r r u p t C o n f i g u r a t i o n r e g i s t e r
Addresses: 9000_000C / 9000_800C / 9001_000C / 9001_800C / 9002_000C /
9002_800C / 9003_000C / 9000_800C
The RX Interrupt Configuration register allows system software to configure the
interrupt for the I/O hub module receive channel.
Register
Register bit
assignment
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
RXBDP
RXBDP
Bit(s)
Access
Mnemonic
Reset
Description
D31:00
R/W
RXBDP
0x0
The first buffer descriptor in the ring. Used when
the W bit is found, which indicates the last buffer
descriptor in the list.
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
BLENSTAT
RXTHRS
Reser
ved
RXFOFIE
RXNCIE
RXPCIE WSTAT
LSTAT
ISTAT
RXFSRIE
RXECIE RXNRIE RXCAIE
FSTAT
Bit(s)
Access
Mnemonic
Reset
Description
D31:28
R/W
RXTHRS
0xF
RX FIFO threshold
An interrupt is generated when the FIFO level
rises above this level.
D27
N/A
Reserved
N/A
N/A
