I / O C O N T R O L M O D U L E
GPIO Configuration registers
60 Hardware Reference NS9215
GPIO
Configuration
Register #8
Address: A090_2020
GPIO
Configuration
Register #9
Address: A090_2024
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO35 GPIO34
GPIO33 GPIO32
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO35 0x18 GPIO[35] configuration
D23:16 R/W GPIO34 0x18 GPIO[34] configuration
D15:08 R/W GPIO33 0x18 GPIO[33] configuration
D07:00 R/W GPIO32 0x18 GPIO[32] configuration
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO39 GPIO38
GPIO37 GPIO36
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO39 0x18 GPIO[39] configuration
D23:16 R/W GPIO38 0x18 GPIO[38] configuration
D15:08 R/W GPIO37 0x18 GPIO[37] configuration
D07:00 R/W GPIO36 0x18 GPIO[36] configuration
