I / O C O N T R O L M O D U L E
GPIO Configuration registers
66 Hardware Reference NS9215
GPIO
Configuration
Register #20
Address: A090_2050
GPIO
Configuration
Register #21
Address: A090_2054
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO83 GPIO82
GPIO81 GPIO80
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO83 0x18 GPIO[83] configuration
D23:16 R/W GPIO82 0x18 GPIO[82] configuration
D15:08 R/W GPIO81 0x18 GPIO[81] configuration
D07:00 R/W GPIO80 0x18 GPIO[80] configuration
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO87 GPIO86
GPIO85 GPIO84
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO87 0x18 GPIO[87] configuration
D23:16 R/W GPIO86 0x18 GPIO[86] configuration
D15:08 R/W GPIO85 0x18 GPIO[85] configuration
D07:00 R/W GPIO84 0x18 GPIO[84] configuration
