E T H E R N E T C O M M U N I C A T I O N M O D U L E
Ethernet Interrupt Status register
318
Hardware Reference NS9215
D21
R/C
RXDONEB
0
Assigned to RX interrupt.
Complete receive frame stored in pool B of system
memory.
D20
R/C
RXDONEC
0
Assigned to RX interrupt.
Complete receive frame stored in pool C of system
memory.
D19
R/C
RXDONED
0
Assigned to RX interrupt.
Complete receive frame stored in pool D of system
memory.
D18
R/C
RXNOBUF
0
Assigned to RX interrupt.
No buffer is available for this frame due to one of
these conditions:
All four buffer rings being disabled
All four buffer rings being full
No available buffer big enough for the frame
D17
R/C
RXBUFFUL
0
Assigned to RX interrupt.
No buffer is available for this frame because all four
buffer rings are disabled or full.
D16
R/C
RXBR
0
Assigned to RX interrupt.
New frame available in the RX_FIFO. This bit is
used for diagnostics.
D15:07
N/A
Reserved
N/A
N/A
D06
R/C
STOVFL
0
Assigned to TX interrupt.
Statistics counter overflow. Individual counters can
be masked using the Carry Register 1 and 2 Mask
registers. The source of this interrupt is cleared by
clearing the counter that overflowed, and by clearing
the associated carry bit in either Carry Register 1 or
Carry Register 2 by writing a 1 to the bit.
D05
R
Not used
0
Always write as 0.
D04
R/C
TXBUFC
0
Assigned to TX interrupt.
I bit set in the Transmit Buffer Descriptor and buffer
closed.
D03
R/C
TXBUFNR
0
Assigned to TX interrupt.
F bit not set in the Transmit Buffer Descriptor when
read from the TX Buffer descriptor RAM.
D02
R/C
TXDONE
0
Assigned to TX interrupt.
Frame transmission complete.
Bits
Access
Mnemonic
Reset
Description
