S Y S T E M C O N T R O L M O D U L E
Timer 0–4 Control registers
164 Hardware Reference NS9215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
T i m e r 0 – 4 C o n t r o l r e g i s t e r s
Addresses: A090 0190 / 0194 / 0198 / 019C / 01A0
D09 R/W T9E 0x0 Timer 9 enable
0
Timer reset
1 Timer enabled
D08 R/W T8E 0x0 Timer 8 enable
0
Timer reset
1 Timer enabled
D07 R/W T7E 0x0 Timer 7 enable
0
Timer reset
1 Timer enabled
D06 R/W T6E 0x0 Timer 6 enable
0
Timer reset
1 Timer enabled
D05 R/W T5E 0x0 Timer 5 enable
0
Timer reset
1 Timer enabled
D04 R/W T4E 0x0 Timer 4 enable
0
Timer reset
1 Timer enabled
D03 R/W T3E 0x0 Timer 3 enable
0
Timer reset
1 Timer enabled
D02 R/W T2E 0x0 Timer 2 enable
0
Timer reset
1 Timer enabled
D01 R/W T1E 0x0 Timer 1 enable
0
Timer reset
1 Timer enabled
D00 R/W T0E 0x0 Timer 0 enable
0
Timer reset
1 Timer enabled
Bits Access Mnemonic Reset Description
