A N A L O G - T O - D I G I T A L C O N V E R T E R ( A D C ) M O D U L E
ADC Output Registers 0-7
478
Hardware Reference NS9215
Register
Register bit
assignment
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
Not used
DOUT
Not used
Bit(s)
Access
Mnemonic
Reset
Description
D31:12
R/W
Not used
0
This field must be written to 0.
D11:00
R
DOUT
0
Provides the output of the ADC for each channel.
