E X T E R N A L D M A
DMA Peripheral Chip Select register
352 Hardware Reference NS9215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D M A P e r i p h e r a l C h i p S e l e c t r e g i s t e r
Address: A080_000C, A080_001C
The DMA Peripheral Chip Select register contains the DMA channel peripheral chip
select definition. The external DMA module has two of these registers.
Register
D24 R/W NCIE 0 Enable NCIP interrupt generation.
D23 R/W ECIE 0 Enable ECIE interrupt generation. This interrupt
should always be enabled during normal
operation.
D22 R/W NRIE 0 Enable NRIP interrupt generation.
D21 R/W CAIE 0 Enable CAIP interrupt generation. This interrupt
should always be enabled during normal
operation.
D20 R/W PCIE 0 Enable PCIP interrupt generation.
D19 R WRAP 0 Read-only debug field that indicates the last
descriptor in the descriptor list.
D18 R DONE 0 Read-only debug field that indicates the status of
the DONE signal.
D17 R LAST 0 Read-only debug field that indicates the last buffer
descriptor in the current data frame.
D16 R FULL 0 Read-only debug field that indicates the status of
the F bit from the current DMA buffer descriptor.
D15:00 R BLEN 0 Read-only debug field that indicates the current
byte transfer count.
Bit(s) Access Mnemonic Reset Description
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
Not used
Not used SEL
