M E M O R Y C O N T R O L L E R
Static Memory Write Delay 0–3 registers
www.digiembedded.com
257
modified during system initialization, or when there are no current or outstanding
transactions. Wait until the memory controller is idle, then enter low-power or
disabled mode.
Register
Register bit
assignment
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
S t a t i c M e m o r y W r i t e D e l a y 0 – 3 r e g i s t e r s
Address: A070 0214 / 0234 / 0254 / 0274
The Static Memory Write Delay 0–3 registers allow you to program the delay from
the chip select to the write access. These registers control the overall period for
the write cycle. It is recommended that these registers be modified during system
initialization, or when there are no current or outstanding transactions. Wait until
the memory controller is idle, then enter low-power or disabled mode.These
registers are not used if the extended wait bit is enabled in the related Static
Memory Configuration register.
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
Reserved
Reserved
WTPG
Bits
Access
Mnemonic
Description
D31:05
N/A
Reserved
N/A (do not modify)
D04:00
R/W
WTPG
Asynchronous page mode read after the first wait state
(WAITPAGE)
00000–11110
(n+1)
clk_out
cycle for read access time. For
asynchronous page mode read for sequential reads, the wait
state time for page mode accesses after the first read is
(WAITPAGE+1) x t
clk_out
11111
32
clk_out
cycles read access time (reset value on
reset_n
)
Number of wait states for asynchronous page mode read accesses
after the first read.
