I / O H U B M O D U L E
[Module] Interrupt and FIFO Status register
374 Hardware Reference NS9215 31 March 2008
D26 R/W* RXFOFIP 0x0 RX FIFO overflow interrupt pending
Set when the RX FIFO finds an overflow
condition.
D25 R/W* RXFSRIP 0x0 RX FIFO service request interrupt pending
(RX)
Set when the RX FIFO level rises above the
receive FIFO threshold (in the RX Interrupt
Configuration register).
D24 R/W* TXNCIP 0x0 Normal completion interrupt pending (TX)
Set when a buffer is closed under normal
conditions. An interrupt is generated when the I bit
is set in the current buffer descriptor.
A normal DMA completion occurs when the
buffer length field expires.
D23 R/W* TXECIP 0x0 Error completion interrupt pending (TX)
Set when the DMA channel finds either a bad
buffer descriptor or a bad data buffer pointer.
The DMA channel remains in the ERROR state
until the CE bit in the DMA Control register is
cleared and then set again. The DMA channel then
uses the buffer descriptor as set in the index
control field.
D22 R/W* TXNRIP 0x0 Buffer not ready interrupt pending (TX)
Set when the DMA channel finds a buffer
descriptor with the F bit not set.
The DMA channel remains in the ERROR state
until the CE bit in the DMA Control register is
cleared and then set again. The DMA channel then
uses the buffer descriptor as set in the index
control field.
D21 R/W* TXCAIP 0x0 Channel abort interrupt pending (TX)
Set when the DMA channel finds the channel
abort (CA) control bit set.
The DMA controller closes the current buffer
descriptor and remains in the IDLE state until the
CA bit is cleared and the CE bit is set.
D20 R/W* TXFUFIP 0x0 TX FIFO underflow interrupt pending
Set when the TX FIFO finds an underflow.
D19 R/W* TXFSRIP 0x0 TX FIFO service request interrupt pending
(TX)
Set when the TX FIFO level drops below the
transmit FIFO threshold (in the TX Interrupt
Configuration register).
Bit(s) Access Mnemonic Reset Description
