SDRAM Initialization
226
Hardware Reference NS9215
10
Set the
SDRAMInit
value in the Dynamic Control register to 01 — Issue SDRAM
Mode command.
11
Program the SDRAM memory 10-bit mode register. The mode register enables
these parameters to be programmed:
A read transaction from the SDRAM memory programs the mode register.
The transfer address contains the value to be programmed. Address bits
31:28 determine the chip select of the specific SDRAM that is being
programmed. The 10-bit mode value must be shifted left per the specific
device being programmed; see the tables following this procedure to
determine the left shift value.
All other address bits must be set to 0.
12
Set the
SDRAMInit
value in the Dynamic Control register to 00 — Issue SDRAM nor-
mal operation command.
13
Enable the buffers by writing a 1 to the buffer enable bit in the Dynamic Config-
uration N register.
The SDRAM is now ready for normal operation.
Left-shift value
table: 32-bit wide
data bus SDRAM
(RBC)
Bit
Parameter
Parameter description
02:00
Burst length
4 for a 32-bit wide external bus
8 for a 16-bit wide external bus
03
Burst type
Sequential
06:04
CAS latency
Dependent on the SDRAM device and operating
frequency
08:07
Operating mode
Standard operation
09
Write burst mode
Programmed burst length
Device size
Configuration
Load Mode register left shift
16M
2 x 1M x 16
11
4 x 2M x 8
12
64M
1 x 2M x 32
12
2 x 4M x 16
12
4 x 8M x 8
13
128M
1 x 4M x 32
12
2 x 8M x 16
13
4 x 16M x 8
14
