M E M O R Y C O N T R O L L E R
Static Memory Output Enable Delay 0–3 registers
www.digiembedded.com 255
Register bit
assignment
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
S t a t i c M e m o r y O u t p u t E n a b l e D e l a y 0 – 3 r e g i s t e r s
Address: A070 0208 / 0228 / 0248 / 0268
The Static Memory Output Enable Delay 0–3 registers allow you to program the delay
from the chip select or address change, whichever is later, to the output enable
assertion. The Static Memory Output Enable Delay register is used in conjunction
with the Static Memory Read Delay registers, to control the width of the output
enable signals. It is recommended that these registers be modified during system
initialization, or when there are no current or outstanding transactions. Wait until
the memory controller is idle, then enter low-power or disabled mode.
Register
Register bit
assignment
Bits Access Mnemonic Description
D31:04 N/A Reserved N/A (do not modify)
D03:00 R/W WWEN Wait write enable (WAITWEN)
0000
One clk_out cycle delay between assertion of chip select and
write enable (reset value on reset_n ).
0001–1111 (n+1) clk_out cycle delay, where the delay is
(WAITWEN+1) x t
clk_out
Delay from chip select assertion to write enable.
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
Reserved
Reserved WOEN
Bits Access Mnemonic Description
D31:04 N/A Reserved N/A (do not modify)
D03:00 R/W WOEN Wait output enable (WAITOEN)
0000 No delay (reset value on reset_n ).
0001–1111n cycle delay, where the delay is
WAITOEN x t
clk_out
Delay from chip select assertion to output enable.
