S Y S T E M C O N T R O L M O D U L E
Timer 5 Control register
166 Hardware Reference NS9215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
T i m e r 5 C o n t r o l r e g i s t e r
Address: A090 01A4
Register
D05:04 R/W Timer mode 0x0 Timer mode
00
Internal timer or external event
01 External low-level gated timer
10 External high-level gated timer
11 Concatenate the lower timer.
Note: When either external gated option is
selected, the time clock select bits deter-
mine the frequency.
D03 R/W Int Sel 0x0 Interrupt select
0
Interrupt disable
1 Generate IRQ
D02 R/W Up Down 0x0 Up/Down select
0
Up counter
1 Down counter
D01 R/W Bit timer 0x0 32 or 16 bit timer
0
16-bit timer
1 32-bit timer
D00 R/W Rel Enbl 0x0 Reload enable
0
Halt at terminal count. The timer must be
disabled, then enabled to reload the timer when
the terminal count is reached.
1 Reload and resume count at terminal count
Bits Access Mnemonic Reset Description
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
TCS
Reserved
Cap Comp Debug Int Clr
Timer
Mode
Int Sel
Up
Down
Bit
timer
Rel
Enbl
Rel
Mode
TM2
TE
