W O R K I N G W I T H T H E C P U
Caches and write buffer
www.digiembedded.com 129
ICache I and M
bit settings
This table gives the I and M bit settings for the ICache, and the associated behavior.
ICache page table
C bit settings
This table shows the page table C bit settings for the ICache (R1 I bit = M bit = 1).
R1 register C and
M bits for DCache
This table gives the R1: Control register C and M bit settings for DCache, and the
associated behavior.
DCache page
table C and B
settings
This table gives the page table C and B bit settings for the DCache (R1: Control
register C bit = M bit = 1), and the associated behavior.
R1 I bit R1 M bit ARM926EJ-S behavior
0 ----- ICache disabled. All instruction fetches are fetched from external memory
(AHB).
1 0 ICache enabled, MMU disabled. All instruction fetches are cachable, with no
protection checks. All addresses are flat-mapped; that is, VA=MVA=PA.
1 1 ICache enabled, MMU enabled. Instruction fetches are cachable or
noncachable, depending on the page descriptor C bit (see “ICache page table
C bit settings” on page 129), and protection checks are performed. All
addresses are remapped from VA to PA, depending on the page entry; that
is, the VA is translated to MVA and the MVA is remapped to a PA.
Page table C
bit Description ARM926EJ-S behavior
0 Noncachable ICache disabled. All instruction fetches are fetched from external
memory.
1 Cachable Cache hit Read from the ICache.
Cache miss Linefill from external memory.
R1 C bit R1 M bit ARM926EJ-S behavior
0 0 DCache disabled. All data accesses are to the external memory.
1 0 DCache enabled, MMU disabled. All data accesses are noncachable,
nonbufferable, with no protection checks. All addresses are flat-mapped; that
is, VA=MVA=PA.
1 1 DCache enabled, MMU enabled. All data accesses are cachable or
noncachable, depending on the page descriptor C bit and B bit (see “DCache
page table C and B settings” on page 129), and protection checks are
performed. All addresses are remapped from VA to PA, depending on the
MMU page table entry; that is, the VA is translated to an MVA and the MVA
is remapped to a PA.
