S Y S T E M C O N T R O L M O D U L E
Miscellaneous System Configuration and Status register
184 Hardware Reference NS9215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
M i s c e l l a n e o u s S y s t e m C o n f i g u r a t i o n a n d S t a t u s r e g i s t e r
Address: A090 0184
The Miscellaneous System Configuration and Status register configures
miscellaneous system configuration bits.
Register
D07:06 N/A Reserved N/A Always write to 00
D05 R/W SPI 0x1 SPI
0
Module reset
1 Module enabled
D04 R/W UART D 0x1 UART D
0
Module reset
1 Module enabled
D03 R/W UART C 0x1 UART C
0
Module reset
1 Module enabled
D02 R/W UART B 0x1 UART B
0
Module reset
1 Module enabled
D01 R/W UART A 0x1 UART A
0
Module reset
1 Module enabled
D00 R/W Eth MAC 0x1 Ethernet MAC
0
Module reset
1 Module enabled
Bits Access Mnemonic Reset Description
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
REV ID
Reserved
AUX/
COMP
Boot
Mode
Boot
width
Mis
bus
resp
Int
reg
acc
End
mode
