[ M o d u l e ] I n t e r r u p t a n d F I F O S t a t u s r e g i s t e r
Addresses: 9000_0000 / 9000_8000 / 9001_0000 / 9001_8000 / 9002_0000 /
9002_8000 / 9003_0000 / 9003_8000
The Interrupt and FIFO Status register allows software to determine the cause of
the current low speed peripheral interrupts and to clear the interrupt bit.
Note:
An access type of R/W* means that the processor must write 1 to clear the
value if the read value is 1. If the read value is 0, the write value must be 0.
Register Offset Description (31:00)
0x9006_0000 – 0x9006_00BF
0x9006_0000 – 0x9006_00FC RTC CSR Space
64-byte Battery Backed RAM
Register Offset Description (31:00)
0x9006_8000 – 0x9006_FFFF IO Hardware Assist CSR Space for Flexible I/O Module 0
Register Offset Description (31:00)
0x9007_0000 – 0x9007_7FFF IO Hardware Assist CSR Space for Flexible I/O Module 1
Register Offset Description (31:00)
0x9008_0000 – 0x9008_FFFF IO Space for Flexible I/O Module 0
Register Offset Description (31:00)
0x9009_0000 – 0x9009_FFFF IO Space for Flexible I/O Module 1
