Statistics registers
www.digiembedded.com
303
HT2
Address: A060 0508
Register bit assignment
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
S t a t i s t i c s r e g i s t e r s
Address: A060 0680 (base register)
The Statistics module has 39 counters and 4 support registers that count and save
Ethernet statistics. The Ethernet General Control Register #2 contains three
Statistics module configuration bits: AUTOZ, CLRCNT, and STEN. The counters
support a “clear on read” capability that is enabled when AUTOZ is set to 1.
Combined
transmit and
receive statistics
counters address
map
The combined transmit and receive statistics counters are incremented for each
good or bad frame, transmitted and received, that falls within the specified frame
length limits of the counter (for example, TR127 counts 65–127 byte frames). The
frame length excludes framing bits and includes the FCS (checksum) bytes. All
counters are 18 bits, with this bit configuration:
Bits
Access
Mnemonic
Reset
Description
D31:00
R/W
HT2
0x00000000
CRC 63:32
HT2
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
HT2
D31:18
R
Reserved
D17:00
R/W
Reset = 0x00000
Count (R/W)
Address
Register
Transmit and receive counters
R/W
A060_0680
TR64
Transmit & receive 64
Byte frame counter
R/W
A060_0684
TR127
Transmit & receive 65
to
127 Byte frame counter
R/W
A060_0688
TR255
Transmit & receive 128
to
255 Byte frame counter
R/W
A060_068C
TR511
Transmit & receive 256
to
511 Byte frame counter
R/W
A060_0690
TR1K
Transmit & receive 512
to
1023 Byte frame counter
R/W
