S E R I A L C O N T R O L M O D U L E : U A R T
Interrupt Enable register
www.digiembedded.com
393
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I n t e r r u p t E n a b l e r e g i s t e r
Address: 9001_1004 / 9001_9004 / 9002_1004 / 9002_9004
Use the Interrupt Enable register to enable interrupt generation on specific events.
Enable the interrupt by writing a 1 to the appropriate bit field(s).
Register
Register bit
assignment
D03:02
R/W
RS485OFF
00
RS485 transceiver deassertion control
In bit times after the stop bit period
00
0
01
1
10
1.5
11
2
D01:00
R/W
RS485ON
00
RS485 transceiver assertion control
In bit times before the falling edge of the start bit
00
0
01
1
10
1.5
11
2
Bits
Access
Mnemonic
Reset
Description
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
MATCH
0
CGAP
BGAP
CTS
TBC
TX_
IDLE
PARITY
FRA
ME
Not used
BREA
K
MATCH
4
RI
Reser
ved
FORCE OFLOW
RXCLS
MATCH
3
MATCH
2
MATCH
1
DSR
DCD
RBC
RX_
IDLE
Bits
Access
Mnemonic
Reset
Description
D31:22
R/W
Not used
0
Write this field to 0.
D21
R/W
Reserved
0
Always write to 0.
D20
R/W
FORCE
0
Enable force complete
Enables interrupt generation when a force character
transmission operation has completed.
