I 2 C M A S T E R / S L A V E I N T E R F A C E
Interrupt Codes
www.digiembedded.com 455
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I n t e r r u p t C o d e s
Interrupts are signaled in the irq_code field in the STATUS_REG , by providing the
appropriate interrupt code (see “Master/slave interrupt codes” on page 455). The
ARM CPU waits for an interrupt by polling the
STATUS_REG or checking the irq signal.
An interrupt is cleared by reading the STATUS_REG , which also forces the irq signal
down (minimum one cycle if another interrupt is stored).
Note: RX_DATA_REG
contains only a received byte if it is accessed after a RX_DATA
master or slave interrupt is signaled. At all other times, the internal master or slave shift
register is accessed with RX_DATA_REG (see “Status Receive Data register” on page 451).
Master/slave
interrupt codes
D12:09 R/W SFW 0xF Spike filter width
A default value of 1 is recommended. Available
values are 0–15.
D08:00 R/W CLREF 0x0 clk_ref[9:1]
The I2C clock on port iic_scl_out is generated
by the system clock divided by the 10-bit value
of clk_ref.
The LSB of clk_ref cannot be programmed, and
is set to 0 internally. The programmed value of
clk_ref[9:1] must be greater than 3.
Bits Access Mnemonic Reset Description
Code Name Master/slave Description
0x0 NO_IRQ N/A No interrupt active
0x1 M_ARBIT_LOST Master Arbitration lost; the transfer has to be repeated
0x2 M_NO_ACK Master No acknowledge by slave
0x3 M_TX_DATA Master TX data required in register TX_DATA
0x4 M_RX_DATA Master RX data available in register RX_DATA
0x5 M_CMD_ACK Master Command acknowledge interrupt
0x6 N/A N/A Reserved
0x7 N/A N/A Reserved
0x8 S_RX_ABORT Slave The transaction is aborted by the master before
the slave performs a
NO_ACK .
0x9 S_CMD_REQ Slave Command request
0xA
x
S_NO_ACK Slave No acknowledge by master ( TX_DATA_REG is
reset)
