S Y S T E M C O N T R O L M O D U L E
Timer Master Control register
162
Hardware Reference NS9215
Register
Register bit
assignment
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
T i m e r M a s t e r C o n t r o l r e g i s t e r
Address: A090 0024
The Timer Master Control register resets and enables the timer in groups, which is
useful when using the timers in PW applications.
Register
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
Reserved
Reserved
Reserved
EIC
Reserved
SERDC
Bits
Access
Mnemonic
Reset
Description
D31:24
N/A
Reserved
N/A
N/A
D23
R/W
EIC
0x0
AHB Error Interrupt Clear
Write a 1, then a 0 to this register to clear the AHB
error interrupt and to clear the AHB Error Detect
Status 1 and AHB Error Detect Status 2 registers.
D22:05
N/A
Reserved
N/A
N/A
D04
R/W
SERDC
0x0
AHB Slave Error Response Detect Config
0
Record error only
1
Generate IRQ
D03:00
N/A
Reserved
N/A
N/A
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
T6HSE
Reserved
T1E
T8RSE
T9HSE
T4E
T9RSE T9LSE
T8LSE T8HSE
T7RSE T7LSE T7HSE T6RSE T6LSE
T9E
T8E
T7E
T6E
T5E
T3E
T2E
T0E
