S E R I A L C O N T R O L M O D U L E : U A R T
Wrapper Configuration register
392 Hardware Reference NS9215
D17 R/W RXFLUSH 0 Resets the contents of the 64-byte RXFIFO.
Write a 1, then a 0 to reset the FIFO.
D16 R/W TXFLUSH N/A Resets the contents of the 64-byte TX FIFO.
Write a 1, then a 0 to reset the FIFO.
D15:14 R RXBYTES 00 Indicates how many bytes are pending in the wrapper.
The wrapper writes to the RX FIFO only when 4 bytes are
received or a buffer close event occurs, such as a
character gap timeout, character match, or error.
D13 R/W RXCLOSE 0 Allows software to close a receive buffer. Hardware
clears this bit when the buffer has been closed.
0
Idle or buffer already closed
1 Software initiated buffer close
D12 N/A Reserved N/A N/A
D11:06 R/W TXFLOW 010000 Selects which signals are routed to the UART for
hardware flow control. Transmit data is halted when the
selected signal is deasserted.
[0] CTS
0
CTS disabled
1 CTS enabled
[1] DCD
0
DCD disabled
1 DCD enabled
[2] DSR
0
DSR disabled
1 DSR enabled
[3] RI
0
RI disabled
1 RI enabled
[4] Software
0
TX disabled
1 TX enabled
[5] Receive character-based flow control
0
Disabled
1 Enabled
D05 R/W RL 0 Remote loopback
Provides an internal remote loopback feature. When the
RL field is set to 1, the receive serial data signal is
connected to the transmit serial data signal.
A local loopback is provided in the UART.
D04 R/W RTS 0 RTS control
0 Controlled directly by UART
1 Deasserted when RX FIFO is half full
Bits Access Mnemonic Reset Description
