E T H E R N E T C O M M U N I C A T I O N M O D U L E
MII Management Write Data register
298
Hardware Reference NS9215
Register bit
assignment
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
M I I M a n a g e m e n t W r i t e D a t a r e g i s t e r
Address: A060 042C
Register
Register bit
assignment
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
M I I M a n a g e m e n t R e a d D a t a r e g i s t e r
Address: A060 0430
Bits
Access
Mnemonic
Reset
Description
D31:13
N/A
Reserved
N/A
N/A
D12:08
R/W
DADR
0x00
MII PHY device address
Represents the 5-bit PHY device address field for
management cycles. Up to 32 different PHY devices
can be addressed.
D07:05
N/A
Reserved
N/A
N/A
D04:00
R/W
RADR
0x00
MII PHY register address
Represents the 5-bit PHY register address field for
management cycles. Up to 32 registers within a single
PHY device can be addressed.
Reserved
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
MWTD
Bits
Access
Mnemonic
Reset
Description
D31:16
N/A
Reserved
N/A
N/A
D15:00
R/W
MWTD
0x0000
MII write data
When this register is written, an MII Management
write cycle is performed using this 16-bit data along
with the preconfigured PHY device and PHY register
addresses defined in the MII Management Address
register. The write operation completes when the
BUSY bit in the MII Management Indicators register
returns to 0.
