Page 69
. . . . .
I / O C O N T R O L M O D U L E
GPIO Configuration registers
www.digiembedded.com
69
GPIO
Configuration
Register #26
Address: A090_2068
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
GPIO_A3
GPIO_A2
GPIO_A1
GPIO_A0
Bit(s)
Access
Mnemonic
Reset
Description
D31:24
R/W
GPIO_A3
0x18
GPIO_A[3] configuration
D23:16
R/W
GPIO_A2
0x18
GPIO_A[2] configuration
D15:08
R/W
GPIO_A1
0x18
GPIO_A[1] configuration
D07:00
R/W
GPIO_A0
0x18
GPIO_A[0] configuration
