Carry register 1 mask register – Digi NS9215 User Manual
Page 312
E T H E R N E T C O M M U N I C A T I O N M O D U L E
Statistics registers
312
Hardware Reference NS9215
Register
Register bit
assignment
Carry Register 1
Mask register
Address: A060 0738
C2
TBY
C2
TPK
C2TBC
C2TMC
Rsvd C2TDF
C2
TED
C2
TSC
C2
TMA
C2
TLC
C2
TXC
C2
TNC
Reserved
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
C2
TUN
C2
TFG
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
Reserved
C2
JTB
C2
TFC
Rsvd
C2
TOV
Bits
Access
Mnemonic
Reset
Description
D31:20
N/A
Reserved
N/A
N/A
D19
R/C
C2TJB
0
Carry register 2 TJBR counter carry bit
D18
R/C
C2TFC
0
Carry register 2 TFCS counter carry bit
D17
N/A
Reserved
N/A
N/A
D16
R/C
C2TOV
0
Carry register 2 TOVR counter carry bit
D15
R/C
C2TUN
0
Carry register 2 TUND counter carry bit
D14
R/C
C2TFG
0
Carry register 2 TFRG counter carry bit
D13
R/C
C2TBY
0
Carry register 2 TBYT counter carry bit
D12
R/C
C2TPK
0
Carry register 2 TPKT counter carry bit
D11
R/C
C2TMC
0
Carry register 2 TMCA counter carry bit
D10
R/C
C2TBC
0
Carry register 2 TBCA counter carry bit
D09
N/A
Reserved
N/A
N/A
D08
R/C
C2TDF
0
Carry register 2TDFR counter carry bit
D07
R/C
C2TED
0
Carry register 2 TEDF counter carry bit
D06
R/C
C2TSC
0
Carry register 2 TSCL counter carry bit
D05
R/C
C2TMA
0
Carry register 2 TMCL counter carry bit
D04
R/C
C2TLC
0
Carry register 2 TLCL counter carry bit
D03
R/C
C2TXC
0
Carry register 2 TXCL counter carry bit
D02
R/C
C2TNC
0
Carry register 2 TNCL counter carry bit
D01:00
N/A
Reserved
N/A
N/A
