P I N O U T ( 2 6 5 )
Memory bus interface
www.digiembedded.com
29
M1
addr[0]
U
I/O
4
Address bus, PLL NR[0]
L1
data[31]
U
I/O
4
Data bus
K2
data[30]
U
I/O
4
Data bus
K1
data[29]
U
I/O
4
Data bus
J1
data[28]
U
I/O
4
Data bus
J2
data[27]
U
I/O
4
Data bus
H1
data[26]
U
I/O
4
Data bus
G1
data[25]
U
I/O
4
Data bus
J3
data[24]
U
I/O
4
Data bus
H2
data[23]
U
I/O
4
Data bus
F1
data[22]
U
I/O
4
Data bus
G2
data[21]
U
I/O
4
Data bus
H3
data[20]
U
I/O
4
Data bus
E1
data[19]
U
I/O
4
Data bus
F2
data[18]
U
I/O
4
Data bus
D1
data[17]
U
I/O
4
Data bus
E2
data[16]
U
I/O
4
Data bus
H4
data[15] / gpio[31]
b
U
I/O
4
Data bus
G3
data[14] / gpio[30]
U
I/O
4
Data bus
G4
data[13] / gpio[29]
U
I/O
4
Data bus
G5
data[12] / gpio[28]
U
I/O
4
Data bus
F3
data[11] / gpio[27]
U
I/O
4
Data bus
F4
data[10] / gpio[26]
U
I/O
4
Data bus
F5
data[9] / gpio[25]
U
I/O
4
Data bus
C1
data[8] / gpio[24]
U
I/O
4
Data bus
E4
data[7] / gpio[23]
U
I/O
4
Data bus
D2
data[6] / gpio[22]
U
I/O
4
Data bus
E3
data[5] / gpio[21]
U
I/O
4
Data bus
B1
data[4] / gpio[20]
U
I/O
4
Data bus
D4
data[3] / gpio[19]
U
I/O
4
Data bus
C2
data[2] / gpio[18]
U
I/O
4
Data bus
B2
data[1] / gpio[17]
U
I/O
4
Data bus
D3
data[0] / gpio[16]
U
I/O
4
Data bus
Pin
Signal
U/D
I/O
OD
Description
