I / O C O N T R O L M O D U L E
GPIO Configuration registers
62 Hardware Reference NS9215
GPIO
Configuration
Register #12
Address: A090_2030
GPIO
Configuration
Register #13
Address: A090_2034
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO51 GPIO50
GPIO49 GPIO48
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO51 0x18 GPIO[51] configuration
D23:16 R/W GPIO50 0x18 GPIO[50] configuration
D15:08 R/W GPIO49 0x18 GPIO[49] configuration
D07:00 R/W GPIO48 0x18 GPIO[48] configuration
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO55 GPIO54
GPIO53 GPIO52
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO55 0x18 GPIO[55] configuration
D23:16 R/W GPIO54 0x18 GPIO[54] configuration
D15:08 R/W GPIO53 0x18 GPIO[53] configuration
D07:00 R/W GPIO52 0x18 GPIO[52] configuration
