M E M O R Y C O N T R O L L E R
Dynamic Memory Configuration 0–3 registers
248
Hardware Reference NS9215
Use the Dynamic Memory Configuration 0–3 registers to program the configuration
information for the relevant dynamic memory chip select. These registers are
usually modified only during system initialization.
Register
Register bit
assignment
Rsvd
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
Rsvd
AM
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
Reserved
Protect BDMC
Reserved
AM1
Reserved
MD
Reserved
Bits
Access
Mnemonic
Description
D31:21
N/A
Reserved
N/A (do not modify)
D20
R/W
Protect
Write protect
0
Writes not protected (reset value on
reset_n
)
1
Write protected
D19
R/W
BDMC
Buffer enable
0
Buffer disabled for accesses to this chip select (reset value on
reset_n
)
1
Buffer enabled for accesses to this chip select. The buffers must
be disabled during SDRAM initialization. The buffers must be
enabled during normal operation.
D18:15
N/A
Reserved
N/A (do not modify)
D14
R/W
AM
Address mapping
0
Reset value on
reset_n
See Table , “Register map,” on page 230 for more information.
D13
N/A
Reserved
N/A (do not modify)
D12:07
R/W
AM1
Address mapping
00000000
Reset value on
reset_n
The SDRAM column and row width and number of banks are
computed automatically from the address mapping.
See "Register map," beginning on page 230, for more information.
D06:05
N/A
Reserved
N/A (do not modify)
D04:03
R/W
MD
Memory device
00
SDRAM (reset value on
reset_n
)
01
Low-power SDRAM
10
Reserved
11
Reserved
D02:00
N/A
Reserved
N/A (do not modify)
