P I N O U T ( 2 6 5 )
System mode
46
Hardware Reference NS9215
sys_mode_2
sys_mode_1
sys_mode_0
Description
0
0
0
manufacturing test
0
0
1
manufacturing test
0
1
0
manufacturing test
0
1
1
normal operation, boundary scan enabled, POR disabled
1
0
0
normal operation, boundary scan enabled, POR enabled
1
0
1
board test mode, all outputs tristated
1
1
0
normal operation, ARM debug enabled, POR disabled
1
1
1
normal operation, ARM debug enabled, POR enabled
