Digi NS9215 User Manual
Page 40
P I N O U T ( 2 6 5 )
General purpose I/O (GPIO)
40
Hardware Reference NS9215
T15
gpio[76]
U
I/O
2
0
PIC_0_CTL_IO[0](I/O)
1
PIC_1_CTL_IO[0](I/O)
2
Ext Timer Event in Ch 2
3
gpio[76]
T16
gpio[77]
U
I/O
2
0
PIC_0_CTL_IO[1](I/O)
1
PIC_1_CTL_IO[1](I/O)
2
Ext Timer Event in Ch 3
3
gpio[77]
R14
gpio[78]
U
I.O
2
0
PIC_0_CTL_IO[2](I/O)
1
PIC_1_CTL_IO[2](I/O)
2
Ext Timer Event in Ch 4
3
gpio[78]
P14
gpio[79]
U
I/O
2
0
PIC_0_CTL_IO[3](I/O)
1
PIC_1_CTL_IO[3](I/O)
2
Ext Timer Event in Ch 5
3
gpio[79]
R17
gpio[80]
U
I/O
2
0
PIC_0_BUS_0[0](I/O)
1
PIC_1_BUS_0[0](I/O)
2
Ext Timer Event in Ch 6 (dup)
3
gpio[80]
P17
gpio[81]
U
I/O
2
0
PIC_0_BUS_0[1](I/O)
1
PIC_1_BUS_0[1](I/O)
2
Ext Timer Event in Ch 7(dup)
3
gpio[81]
N16
gpio[82]
U
I/O
2
0
PIC_0_BUS_0[2](I/O)
1
PIC_1_BUS_0[2](I/O)
2
Ext Timer Event in Ch 8 (dup)
3
gpio[82]
N17
gpio[83]
U
I/O
2
0
PIC_0_BUS_0[3](I/O)
1
PIC_1_BUS_0[3](I/O)
2
Ext Timer Event in Ch 9 (dup)
3
gpio[83]
M17
gpio[84]
U
I/O
2
0
PIC_0_BUS_0[4](I/O)
1
PIC_1_BUS_0[4](I/O)
2
Ext Timer Event Out Ch 0
3
gpio[84]
L15
gpio[85]
U
I/O
2
0
PIC_0_BUS_0[5](I/O)
1
PIC_1_BUS_0[5](I/O)
2
Ext Timer Event Out Ch 1
3
gpio[85]
Pin
Signal
U/D
I/O
OD
Description
