I / O C O N T R O L M O D U L E
GPIO Configuration registers
www.digiembedded.com 59
GPIO
Configuration
Register #6
Address: A090_2018
GPIO
Configuration
Register #7
Address: A090_201C
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO27 GPIO26
GPIO25 GPIO24
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO27 0x00 GPIO[27] configuration
D23:16 R/W GPIO26 0x00 GPIO[26] configuration
D15:08 R/W GPIO25 0x00 GPIO[25] configuration
D07:00 R/W GPIO24 0x00 GPIO[24] configuration
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO39 GPIO38
GPIO37 GPIO36
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO31 0x00 GPIO[31] configuration
D23:16 R/W GPIO30 0x00 GPIO[30] configuration
D15:08 R/W GPIO29 0x00 GPIO[29] configuration
D07:00 R/W GPIO28 0x00 GPIO[28] configuration
