Timer Master Control register
www.digiembedded.com
163
Register bit
assignment
Bits
Access
Mnemonic
Reset
Description
D31:22
N/A
Reserved
N/A
N/A
D21
R/W
T9RSE
0x0
Timer 9 reload step enable
0
Reload Step register disabled
1
Reload Step register enabled
D20
R/W
T9LSE
0x0
Timer 9 low step enable
0
Low Step register disabled
1
Low Step register enabled
D19
R/W
T9HSE
0x0
Timer 9 high step enable
0
High Step register disabled
1
High Step register enabled
D18
R/W
T8RSE
0x0
Timer 8 reload step enable
0
Reload Step register disabled
1
Reload Step register enabled
D17
R/W
T8LSE
0x0
Timer 8 low step enable
0
Low Step register disabled
1
Low Step register enabled
D16
R/W
T8HSE
0x0
Timer 8 high step enable
0
High Step register disabled
1
High Step register enabled
D15
R/W
T7RSE
0x0
Timer 7 reload step enable
0
Reload Step register disabled
1
Reload Step register enabled
D14
R/W
T7LSE
0x0
Timer 7 low step enable
0
Low Step register disabled
1
Low Step register enabled
D13
R/W
T7HSE
0x0
Timer 7 high step enable
0
High Step register disabled
1
High Step register enabled
D12
R/W
T6RSE
0x0
Timer 6 reload step enable
0
Reload Step register disabled
1
Reload Step register enabled
D11
R/W
T6LSE
0x0
Timer 6 low step enable
0
Low Step register disabled
1
Low Step register enabled
D10
R/W
T6HSE
0x0
Timer 6 high step enable
0
High Step register disabled
1
High Step register enabled
