I / O C O N T R O L M O D U L E
GPIO Configuration registers
64 Hardware Reference NS9215
GPIO
Configuration
Register #16
Address: A090_2040
GPIO
Configuration
Register #17
Address: A090_2044
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO67 GPIO66
GPIO65 GPIO64
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO67 0x18 GPIO[67] configuration
D23:16 R/W GPIO66 0x18 GPIO[66] configuration
D15:08 R/W GPIO65 0x18 GPIO[65] configuration
D07:00 R/W GPIO64 0x18 GPIO[64] configuration
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
GPIO71 GPIO70
GPIO69 GPIO68
Bit(s) Access Mnemonic Reset Description
D31:24 R/W GPIO71 0x18 GPIO[71] configuration
D23:16 R/W GPIO70 0x18 GPIO[70] configuration
D15:08 R/W GPIO69 0x18 GPIO[69] configuration
D07:00 R/W GPIO68 0x18 GPIO[68] configuration
