A N A L O G - T O - D I G I T A L C O N V E R T E R ( A D C ) M O D U L E
ADC control and status registers
www.digiembedded.com 475
2
Set up the ADC DMA control registers and buffer descriptors (UART channel D).
3
Reset the ADC module by writing a 0 then a 1 to bit 8 in the Module Reset
register at address A090 0180.
4
Flush the ADC DMA FIFO by writing a 1 then a 0 to bit 17 in UART Channel D
Wrapper Configuration register at address 9002 9000.
5
Enable the ADC DMA channel by writing a 1 then a 0 to bit 31 in the UART D DMA
RX Control register at address 9002 8004. 6. Start the ADC by writing a 1 to bit
31 in the ADC Configuration register at address 9003 9000.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A D C c o n t r o l a n d s t a t u s r e g i s t e r s
The ADC configuration registers are located at offset 0x9003_9000.
Register address
map
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A D C C o n f i g u r a t i o n r e g i s t e r
Address: 9003_9000
The ADC Configuration register is the primary Wrapper Configuration register.
Address Description Access Reset value
9003_9000 ADC Configuration register R/W 0x00000000
9003_9004 ADC Clock Configuration register R/W 0x00000000
9003_9008 ADC Output 0 register R/W 0x00000000
9003_900C ADC Output 1 register R/W 0x00000000
9003_9010 ADC Output 2 register R/W 0x00000000
9003_9014 ADC Output 3 register R/W 0x00000000
9003_9018 ADC Output 4 register R/W 0x00000000
9003_901C ADC Output 5 register R/W 0x00000000
9003_9020 ADC Output 6 register R/W 0x00000000
9003_9024 ADC Output 7 register R/W 0x00000000
